SPECIFICATION SHEET
Name of Vessel
Busy Bee
Previous Name
Britoil 28
Registry
Panama
IMO No./ Call sign
9186285/ HO7702
Builders
Fujian Fishery Shipyard, Singapore
Year of Delivery
1998
Type Ocean Going / Anchor Handling / Towing Tug
Classification
Russian Maritime Register of Shipping
KM* Tug
Length over all (LOA)
32.0M
Breadth
9.5M
Depth
4.5M
Draft
3.0M (Designed) / 4.1M (Max)
GRT / NRT / DWT 342T / 102T / 246T
Clear Deck Space
7.5M x 8.0M
Speed
12.0 knots
Bollard Pull
45 metric tonnes
Endurance
17 days
Accommodation
Fully air conditioned for 14 .men
Lifesaving
To meet SOLAS requirement
Firefighting
To meet SOLAS requirement
Fuel
168 mt
Fresh Water
48 mt
Main Engines
2 x YANMAR T260A-ET medium speed six cylinder diesel engines producing 1600 bhp each @ 750 rpm
Generators
2 x 135 KW 415/3/50 driven by 2 x Detroit Diesel 6-71T diesel engines
M.E. Consumption
11,000 litres MGO and 20 litreslube oil per 24 hours @ fullpower. 9,000 litres MGO and10 litres lube oil per 24 hours@ economic cruising speed of10 knots
Generator Consumption
240 litres MGO and 4 litres lube oil per 24 hours
Propulsion
2 x YANMAR Y-2002 3.01:1 reverse reduction gearboxes coupled to four bladed 2300mm diameter fixed pitch propellers turning in Kort nozzles @ 250 rpm
* Details given in good faith and are believed to be correct but not guaranteed.
DOWNLOAD BROCHURE
Busy Bee.pdf346.57 KB
