SPECIFICATION SHEET
Builders
SLOB, PAPENDRECHT, NL
Year of Delivery
Mar 18, 1993
Hull No.
9104
Type
Double Hull Product Carrier
Classification / Notation
Registro Italiano Navale/ C* oil tanker ESP - double hull;
unrestricted navigation Chemical tanker ESP-IMO 2
Length Over All (LOA)
122.8 m
Length Between Particulars (LBP)
117.71 m
Breadth (Moulded)
16.7 m
Depth (Moulded)
8.95 m
Draft (Summer)
6.781 m
GRT / NRT
5050 t / 2829 T
Deadweight
9431 MT
Lightship
2454.6 MT
Accommodation
15 crewmen
Speed / Consumption
13 Knots / 12 T/day
Tanks Capacity
Cargo: 9906 m3 at 98% excluding Slop Tanks Slop: 25 m3
Ballast: 3292 m3
Diesel Oil: 176 m3
Fresh Water: 68T
Propulsion System
1 - CCP HRP-52
Main Engine
1 x KRUPP AK 8M453C, 4062 bhp
M/E Turbo Charger
BBC VTR 304-II
Diesel Generator
1 x 6BDXC-750-100A, BHP900/RPM 750 1 x SHAFT 680 KWS
Emergency Generator
1 x 3412 KW583, RPM 1500
Boiler
2 x 1,000KG/HR at 10 BARS
Separators
2 x Fuel Oil Separator, 2 x Diesel Oil & 1 x Lub. Oil Separator
Pumping System
Cargo pump: 6 x Deep well electrical driven pumps 280 m3/h Stripping pump: 1 x 163m3/hr
Ballast pump: 2 x electrical driven pump 300 m3/h
Manifolds
7 x 300mm
Cargo Heating
All cargo tanks are coiled / Material of heating coil: Stainless steel 158F Max temperature cargo can be loaded
158F Max temperature cargo can be maintained
Crane
1 x 2.2 Tonnes SWL Hydraulic
Steering Gear
1 x hydraulic IPE 3-16101
Anchor
2 x Fore castle
Anchor Chains
1 x 9 shackles (stbd) - Fore castle 1 x 9 shackles (port)
Windlass
Hydraulic
Bow Thrusters
1 x 400kW
Lifesaving / Firefighting
1 x Free fallL/Boat 15 persons, 1 x Rescue boat 6 persons capacity 2 x L/Raft 20 & 16 persons capacity
1 x L/Raft 6 persons capacity
6 x Fire Monitor capacity 25m3/h across vessel’s decks Navigation Equipment
ARPA Radar, Inmarsat-C, Navtex, EPIRB, Magnetic Compass, Gyro Compass, GPS, AIS, Echo-sounder, VHF, ECDIS
* Details given in good faith and are believed to be correct but not guaranteed.
